The basic function principle of cone crusher is to use a vertical inner cone to break materials by eccentric rotation in another fixed outer cone. The base of the crusher is installed on the reinforced concrete foundation, the outer cone is fixed on the flange of the base, and the inner cone is installed on the vertical shaft of the crusher. The upper end of the vertical shaft is suspended on the beam by nuts and shaft sleeves; The lower end of the vertical shaft is inserted into the eccentric hole. The motor drives the eccentric sleeve to rotate through the triangular belt pulley, transmission shaft and large and small bevel gears.

Precautions during the operation of cone crusher: (1) the ore must be fed in the middle of the distribution plate, and it is not allowed to feed the ore directly into the crushing chamber. In order to prevent the crusher from overload and uneven wear of the lining plate. The correct ore feeding condition is that the ore is evenly dispersed in the crushing cavity through the distribution plate, and the ore Fed cannot be higher than the level of the rolling mortar wall (2) The ore feeding size of the crusher is ≤ 85% of the ore feeding port size, Shenyang spring cone crusher, otherwise it will lead to the reduction of the output of the crusher and the damage of some other parts of the cone crusher. The crusher is not allowed to start with load. The manufacturer of spring cone crusher will cause accidents when starting with load.

A sealing box is installed above the lower frame of the hydraulic cone crusher. The price of the spring cone crusher is matched with the spherical sealing ring under the crushing cone, and the accessories of the spring cone crusher can achieve the purpose of lubrication and dust prevention. The sealing ring is installed on the supporting ring, which is fixed under the crushing cone by bolts. In order to ensure the effective operation of the seal ring, we must solve the problem of looseness of the fixing bolts of the support ring. We have adopted many methods, such as using thread fastening glue and spot welding of nuts and support ring, which have not achieved ideal results. After that, after the fixing bolts of the support ring are tightened, we weld the support ring and the broken cone body together for fixation, so that the two become a whole, which effectively prevents the sealing ring from falling off and ensures the tightness of the sealing part.

Spring cone crusher manufacturer - Jianye mine (online consultation) - Shenyang spring cone crusher is provided by Shenyang Jianye Mine Equipment Co., Ltd. Shenyang Jianye mining equipment Co., Ltd. has invested a lot of enthusiasm and enthusiasm in the field of crushing and grinding equipment. Jianye mining has always been customer-centered, created value for customers, and won the market with quality and service. We sincerely hope to cooperate with all sectors of society to create success and brilliance. Welcome to inquire about relevant business. Contact person: President Wang.
