Vibrating Bottom Unloader

——Outstanding health conditions
——Low power consumption
——Easy maintenance

Application&advantage

Application：

ZDXL discharger can achieve bulk materials discharging uniformly for all kinds of silos

as concrete silos, steel silos and plastic silos ,and ensure discharging completely for

round silo ,square silo and rectangle silo.

Performance Characteristics:

1. Low consumption —— ZDXL vibrating discharger equipped small vibration

motor to decrease energy consumption.

2.Low maintenance requirements —— All bearings are permanent lubrication, no

lubrication is needed in routine maintenance; the structure of vibration discharger

is strong and maintenance-free, which reduces the maintenance time to the greatest

extent.

3.Reasonable design ensure good sanitation—— All components touching materials

are all adopted streamlined geometry design ,ensure the discharging completely

without any automatic grading device; this kind of discharger in dust-proof design

to minimize material residue and avoid material residue essentially.

Working principle

This machine is installed under the flour bin/silo bottom, for discharging materials

uniformly with the motion of vibrating. Materials flow down to the discharging

hopper and then under the vibration of motor, materials will flow through discharging

plate evenly and gradually without being blocked.

Features

1) Discharging plat taper: 30° for flour and 55° for bran.

2) Vibrate motor can be adjusted to meet various vibration force requirements.

3) Chromed clamps and wear resistant sleeve.

4) Discharge flour equably and continuously.

5) Smooth running with low noise.

Discharging Disk

Conical discharging disk locates at the center part of discharging hopper,

it pushes the material discharging slowly and uniformly from outlet,

meanwhile, it can prevents the material from blocking.
